A large group of figures crowded in a dark hall, lit unevenly; some faces catch the light while others fall away.
surface

Keep one place under watch.

Stage 1 — the same window

Still Under Watch

One place, different questions

The window above does not zoom toward a hidden truth. Move it where you like, then put it under three instruments. Each one answers a single, narrower question — and refuses the others.

Documented fact

Surface

visible light · topography

At extreme scale the paint stops behaving like an illusion and becomes material: ridges of impasto, drying cracks, small losses, the weave of the canvas.

Supports
A precise record of the present surface. The Rijksmuseum's 717-gigapixel photograph was assembled from 8,439 individual photographs at 5 micrometre pixel spacing — 5.6 terabytes, aligned with AI-assisted stitching.
Cannot establish
What lies beneath the visible paint, or which passage is original and which is a later hand.
Note
The reproduction on this page is an ordinary public-domain image. It is not that 717-gigapixel file.
Documentary research image

Calcium

MA-XRF elemental map

Macro X-ray fluorescence maps where a single chemical element sits across the whole canvas. Calcium traces chalk — and chalk traced something no one had seen.

Supports
A chalk-rich, beige preparatory sketch under the paint, in which Rembrandt is visibly searching: feathers altered, a leg moved, a possible sword, more spears than the finished picture keeps.
Cannot establish
The order or the date of those changes, or the intention behind them. A map of an element is not a mind.
Label
Rijksmuseum MA-XRF calcium map — documentary research image. Not a reconstruction and not a photograph of the sketch.
Newly composed model

Lead

diagram over documented findings

Macro-XRF, with targeted samples and synchrotron work, established a lead-rich oil impregnation beneath the ground layer. The lead map showed broad semicircular brushstrokes and the imprint of the original stretcher along the edges.

Inference
It was most likely applied to protect a canvas intended to hang against a damp outer wall.
Cannot establish
Who applied it, exactly when, or that protection was the only motive.
Label
The overlay in the window is a newly composed diagram of that pattern. It is a model, not the museum's lead map.

Modes engaged: 0 of 3.

Reproduction: Rembrandt van Rijn, The Night Watch, 1642, Rijksmuseum, Amsterdam. Public-domain reproduction — image source Wikimedia Commons / Rijksmuseum, Public Domain Mark. It is not a record of the present treatment state. Image file on Wikimedia Commons

Calcium map: Rijksmuseum, Operation Night Watch, MA-XRF calcium map — documentary research image, used inside the watch window only. Rijksmuseum press release on the preparatory sketch

Rijksmuseum MA-XRF calcium map of The Night Watch: a pale grey elemental image in which the chalk-rich preparatory sketch and altered contours appear.

Rijksmuseum · Operation Night Watch · MA-XRF calcium map · documentary research image
